Mechanical
Dimensions: Ø197 x 35 mm (Ø7.8 x 1.4")
Weight:
Without mount: 580 g (1.3 lb)
With mount: 720 g (1.6 lb)
Enclosure Material: Polycarbonate
Mount Material: Stainless steel (SUS304)
Weatherproofing: IP54
Hardware
Networking Interface: (1) GbE RJ45 port
Management Interface: Ethernet, Bluetooth
Power Method: PoE
Power Supply: UniFi PoE switch, PoE adapter (not included)
Supported Voltage Range: 44—57V DC
Max Power Consumption: 13W
Max TX Power:
2.4 GHz: 22 dBm
5 GHz: 26 dBm
MIMO:
2.4 GHz: 2 x 2 (UL MU-MIMO)
5 GHz: 4 x 4 (DL/UL MU-MIMO)
Max Data Rate:
2.4 GHz: 573.5 Mbps (BW40)
5 GHz: 4.8 Gbps (BW160)
Antenna Gain:
2.4 GHz: 4 dBi
5 GHz: 6 dBi
LEDs: White/blue
Button: Factory reset
Mounting: Wall, ceiling (included)
Operating Temperature: -30 to 60°C (-22 to 140°F)
Operating Humidity: 5 to 95% non-condensing
Certifications: CE, FCC, IC
Software
WiFi Standards: 802.11a/b/g/n/ac/ax (WiFi 6)
Wireless Security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID: 8 per radio
VLAN: 802.1Q
Advanced QoS: Per-user rate limiting
Guest Traffic Isolation: Supported
Concurrent Clients: 350+
Zero Wait DFS: Yes (upcoming firmware support)
Supported Data Rates:
802.11a: 6 to 54 Mbps
802.11b: 1 to 11 Mbps
802.11g: 6 to 54 Mbps
802.11n: 6.5 Mbps to 600 Mbps
802.11ac: 6.5 Mbps to 3.4 Gbps
802.11ax (WiFi 6): 7.3 Mbps to 4.8 Gbps
Application Requirements
UniFi Network Version: 6.1.56 and later
