About Ubiquiti UniFi Switch Lite 16 PoE, Layer 2

A wall-mountable, 16-port, Layer 2 PoE switch with a fanless cooling system.

  • (8) GbE PoE+, (8) GbE ports
  • 45W total PoE availability
  • Wall mountable
Mechanical
Dimensions: 192 x 185 x 44 mm (7.6 x 7.3 x 1.7 inches)
Weight: 1.2 kg (2.6 lb)
Enclosure Material: Polycarbonate

Hardware
Management Interface: Ethernet In-Band
Networking Interface: 16 GbE RJ45 ports
PoE Interface: 8 PoE/PoE+ (Pins 1, 2+; 3, 6-)
Total Non-Blocking Throughput: 16 Gbps
Switching Capacity: 32 Gbps
Forwarding Rate: 23.808 Mpps
Power Method: Universal input, 100—240V AC
Power Supply: AC/DC, internal, 60W
Max. Power Consumption: 15W (excluding PoE output)
Total Available PoE: 45W
Max. PoE Wattage per Port: PoE+: 30W
Button: Factory reset
Ambient Operating Temperature: -15 to 40°C (5 to 104°F)
Ambient Operating Humidity: 10 to 90% non-condensing
Certifications: CE, FCC, IC

Switching Features
Layer 2 Features:
IGMP snooping
STP/RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast/broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping/guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs
Layer 3 Features: Not specified

LEDs
System: Status
Ethernet: PoE, Speed/link/activity
PoE: Link/activity

Application Requirements
UniFi Network Version: 7.2.94 and later



SKU USW-LITE-16-POE
MPN USW-LITE-16-POE
Brand Ubiquiti
Shipping Weight 1.4600kg
Shipping Width 0.300m
Shipping Height 0.090m
Shipping Length 0.240m
Unit Of Measure ea

1 Year Warranty
