About Ubiquiti UniFi Wi-Fi 6 Lite Dual Band AP

Compact, ceiling-mounted WiFi 6 AP with 4 spatial streams ideal for smaller offices.

  • Wi-Fi 6 (802.11ax)
  • Up to 1501 Mb/s Throughput
  • 2.4 GHz / 5 GHz (Dual-Band)
  • 1 x PoE-Compliant Gigabit Ethernet Port
  • Wall and Ceiling Mountable
  • WPA-PSK / WPA-Enterprise Authentication
  • Compact Design
  • Supports UniFi Network Controller
Mechanical
Dimensions: Ø160 x 33 mm (Ø6.3 x 1.3")
Weight: Without mount: 300 g (10.6 oz), With mount: 315 g (11.1 oz)
Enclosure Material: Polycarbonate, aluminum
Mount Material: Polycarbonate, SGCC steel

Hardware
Networking Interface: (1) GbE RJ45 port
Management Interface: Ethernet, Bluetooth
Power Method: PoE, Passive PoE (48V)
Power Supply: PoE or optional 48V, 0.32A PoE adapter (not included)
Supported Voltage Range: 44—57V DC
Max Power Consumption: 12W
Max TX Power: 2.4 GHz: 23 dBm
5 GHz: 23 dBm
MIMO: 2.4 GHz: 2 x 2 (SU-MIMO)
5 GHz: 2 x 2 (DL/UL MU-MIMO)
Max Data Rate: 2.4 GHz: 300 Mbps (BW40)
5 GHz: 1.2 Gbps (BW80)
Antenna Gain: 2.4 GHz: 2.8 dBi
5 GHz: 3 dBi
LEDs: White/blue
Button: Factory reset
Mounting: Wall, ceiling (included)
Operating Temperature: -30 to 60°C (-22 to 140°F)
Operating Humidity: 5 to 95% non-condensing
Certifications: CE, FCC, IC

Software
WiFi Standards: 802.11a/b/g/n/ac/ax (WiFi 6)
Wireless Security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID: 8 per radio
VLAN: 802.1Q
Advanced QoS: Per-user rate limiting
Guest Traffic Isolation: Supported
Concurrent Clients: 300+
Supported Data Rates: 802.11a: 6 to 54 Mbps
802.11b: 1 to 11 Mbps
802.11g: 6 to 54 Mbps
802.11n: 6.5 Mbps to 300 Mbps
802.11ac: 6.5 Mbps to 866.7 Mbps
802.11ax (WiFi 6): 7.3 Mbps to 1.2 Gbps

Application Requirements
UniFi Network Version: 5.14.3 and later



SKU U6-LITE
MPN NHU-U6-LITE
Brand Ubiquiti
Shipping Weight 0.0500kg
Shipping Width 0.050m
Shipping Height 0.050m
Shipping Length 0.050m
Shipping Cubic 0.000125000m3
Unit Of Measure ea

1 Year Warranty

Need more information or assistance with this product?

Contact us on 1300 665 970 or complete an online enquiry and one of our staff members will get back to you as soon as possible.

SKU: U6-LITE • MPN: NHU-U6-LITE
