Image Sensor:
- 1/2.7” Progressive Scan CMOS
- Shutter Speed: 1/3 to 1/10000 s
- Minimum Illumination: 0.005 Lux (color), 0 Lux with IR/White light
- Day/Night Mechanism: IR Cut Filter, switchable (Unified/Scheduled/Auto)
Lens:
- Fixed Focal Lens, 2.8/4 mm, F1.6 aperture
- Field of View (FOV):
- 2.8 mm: Horizontal (111.4°), Vertical (58.8°), Diagonal (134°)
- 4 mm: Horizontal (91.5°), Vertical (46.1°), Diagonal (109.6°)
- DORI Distance:
- 2.8 mm: Detect (85 m), Observe (35 m), Recognize (17 m), Identify (8 m)
- 4 mm: Detect (107 m), Observe (44 m), Recognize (21 m), Identify (11 m)
- Angle Adjustment: Pan (0° to 360°), Tilt (0° to 85°), Rotation (0° to 360°)
Illuminator:
- IR LED: 4 LEDs, 30m range, 850nm wavelength
- White LED: 4 LEDs, 30m range
- Control: Auto/Scheduled/Always on/Always off
Video:
- Max. Resolution: 3840 x 2160
- Main Stream: Up to 25fps, various resolutions
- Sub-Stream: Up to 25fps, lower resolutions
- Video Compression: H.265+/H.265/H.264+/H.264
- Bit Rate Control: CBR, VBR
Image:
- Settings: Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, etc.
- Enhancement: BLC, 3D DNR, HLC, SmartIR
- Wide Dynamic Range: 120 dB
- Privacy Mask: Up to 4 masks
Audio:
- Two-Way Audio, with input/output
- Compression: G.711 alaw, 64 Kbps
- Environment Noise Filtering
Network:
- Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
- ONVIF: Yes
- Simultaneous Live View: 3 main streams & 3 sub-streams
- Security: Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
Alarm and Event Management:
- Smart Events: Intrusion, Line-Crossing, Region Entering/Exiting, Object Abandoned/Removal, Loitering, People, Vehicle, Abnormal Sound, Scene Change Detection
- Basic Events: Motion Detection (Enhanced with Human & Vehicle Classification), Video Tampering, Illegal Login
- Alarm Linkage: Memory Card Recording, Message Push, Audible Warning, White Light Flashing
Interfaces:
- Network Interface: 1 RJ45 10/100M Ethernet Port, PoE
- On-board Storage: MicroSD Card Slot, up to 512 GB
- Built-in Microphone and Speaker
General:
- Operating Temperature: -30–60 °C
- Storage Temperature: -40–60 °C
- Humidity: 95% or less (non-condensing)
- Protection: IP67 Weatherproof
- Power Supply: 12V DC, PoE (802.3af/at)
- Dimensions: 4.4 × 4.4 × 3.3 in
- Certifications: CE, NTRA, VCCI, KC, BSMI, FCC, IC
