About Rocket 5AC PTP Lite airMAX AC BaseStation

airMAX AC Technology for up to 500+ Mbps throughput.

  • 5 GHz frequency band
  • 500+ Mbps throughput
  • 50+ client capacity
  • Dedicated spectral analysis radio
Mechanical
Dimensions: 162 x 84 x 37 mm (6.4 x 3.3 x 1.5")
Weight: 250 g (8.8 oz)
Enclosure Material: UV-stabilized plastic

Hardware
Networking Interface: (1) GbE RJ45 port
Power Method: Passive PoE 2-pair (4, 5+; 7, 8 return)
Power Supply: 24V, 0.5A gigabit PoE adapter (included)
Supported Voltage Range: 20–27V DC
Max Power Consumption: 8.5W
ESD/EMP Protection: Air/contact ± 24kV
RF Connectors: (2) RP-SMA (waterproof)
LEDs: Power, LAN, (4) signal strength
Shock and Vibration: ETSI300-019-1.4
Operating Temperature: -40 to 80°C (-40 to 176°F)
Operating Humidity: 5 to 95% non-condensing
Certifications: CE, FCC, IC

Management Radio
Frequency Range: 5150 – 5875 MHz (Worldwide)



SKU R5AC-LITE
Brand Ubiquiti
Shipping Weight 0.2000kg
Shipping Width 0.200m
Shipping Height 0.200m
Shipping Length 0.050m
Shipping Cubic 0.002000000m3

1 Year Warranty
