About Ubiquiti U7-Pro-XGS UniFi AP WiFi7 10GbE Indoor White

Ubiquiti U7-Pro-XGS UniFi AP WiFi7 10GbE Indoor - No POE Injector

Unifi U7-Pro-XGS Ceiling-mounted 8-stream WiFi 7 AP with dedicated spectral scanning radio and 10/5/2.5/1 GbE support.

WiFi 7 with 6 GHz support

8 spatial streams

Real-time spectral analysis for enhanced channel selection

160 m² (1,750 ft²) coverage

500+ connected devices

Powered using PoE++

10 GbE uplink





Technical Specifications

Mechanical
Dimensions Ø215 x 32.5 mm (Ø8.5 x 1.3")
Weight 800 g (1.8 lb)
Enclosure material Polycarbonate, aluminum
Mount material Stainless steel (SUS304), galvanized steel (SGCC)
Hardware
Networking interface (1) 1/2.5/5/10 GbE RJ45 port
Management interface Ethernet
Power method PoE++
Power supply UniFi PoE switch
Supported voltage range 42.5—57V DC
Max. power consumption 29W
Max. TX power
2.4 GHz
5 GHz
6 GHz
23 dBm
29 dBm
24 dBm
MIMO
2.4 GHz
5 GHz
6 GHz
2 x 2 (DL/UL MU-MIMO)
4 x 4 (DL/UL MU-MIMO)
2 x 2 (DL/UL MU-MIMO)
Max. data rate
2.4 GHz
5 GHz
6 GHz
688 Mbps (BW40)
8.6 Gbps (BW240)
5.7 Gbps (BW320)
Antenna gain
2.4 GHz
5 GHz
6 GHz
4 dBi
6 dBi
6 dBi
LEDs White/blue
Button Factory reset
Mounting Wall, ceiling (Included)
Ambient operating temperature -30 to 40° C (-22 to 104° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11a/b/g/n/ac/ax/be (WiFi 6, WiFi 7)
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 500+
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
802.11be (WiFi 7)
5 GHz
6 GHz
7.3 Mbps to 8.6 Gbps (MCS0 - MCS13 NSS1/2/3/4, EHT 20/40/80/160/240)
7.3 Mbps to 5.7 Gbps (MCS0 - MCS13 NSS1/2, EHT 20/40/80/160/240/320
SKU U-PRO-XGS
MPN U7-PRO-XGS
Brand Ubiquiti
Shipping Weight 2.0000kg
Shipping Width 0.300m
Shipping Height 0.150m
Shipping Length 0.300m
Shipping Cubic 0.013500000m3
Unit Of Measure ea
No brochure is available for this product.

Need more information or assistance with this product?

Contact us on 1300 665 970 or complete an online enquiry and one of our staff members will get back to you as soon as possible.

SKU: U-PRO-XGS • MPN: U7-PRO-XGS
